HT-C-5S1 Hydraulic Smart Card Laminator

HT-C-5S1 RFID Contact less Smart Card Laminating Machine is an industrial lamination unit for plastic substrates. The unique technologies integrated into the unit include individual heating, cooling and pressure control circuits. It with simple man-machine screen, easy to operate, with Italy intermational standard oil cylinder, balance pressure, low noise and small vibration.Heating lamination plates are made of ductile iron, keep it never distortion. It is suitable for laminating and procesting all kinds of plastic cards, special for contact less IC and ID inlay cards.

Get A Quote Contact Us

HT-C-5W2-A3 PLC Touchscreen Laminator A3 Integrated Machine

Detail Parameters Get A Quote

Format	320480mm（Up to 520350mm）
ISO CR-80 Templates	A25-up layout for standard ISO Cards on a A3 sheet
Speed	Output up to 1200 cards/cycle (ISO CR-80 cards)
Loading	3 openings of heating, 3 openings of cooling
Controlling Method	Microcomputer
Pressure Method	Oil hydraulic pressure system
Pressure Range	0~160 bar (0~2300 psi), 3 steps pressure
Heating Method	Heating elements (Heating tubes) - PID
Cooling Method	Water cooling (water in / water out)
Power	AC380V, 50/60Hz - 5HP
Machine Weight (Packed)	Approximately 1400 KGS
Total Shipping Dimensions	H1200×W900×H1960 mm (1 crate)
